Graco XM PFP - Operator Command Mode Screens Overview

Appendix A - User Interface Display
3A2776K 75
Operator Command Mode Screens
To enter the Operator Command Functions screens, turn the setup key lock (DJ) to the left.
See F
IG. 7 on page 15.
Operator Command Mode Screens Navigation Diagram
Run (Fluid Control) Screens
Park Pump
Pump Mode
Spray Mode
(Spray Mode shown)
Restrictor
Ratio
Test Screens
Valve Test
Batch Test
Pump Test
Information Screens
(Pump Volume Test shown)
Weight/Volume
Alarm Information
Maintenance 1
Totalizer
Alarm Log
Maintenance 2
Supply Screen
Go to primary screen
in each section
