Appendix B - Alarms
86 3A2776K
Alarm Code Key
Use the following table as a quick guide to determine alarm code meaning.
Digit 1 Digit 2 Digit 3 Digit 4
Code Event Code Mode (Char 2) Code Location (Char 3) Code Zone (Char 4)
A Current 1 Low Alarm A Material A 1 Tank A
F Flow 2 Low Deviation B Material B 2 Tank B
L Tank Level 3 High Deviation C Controller A Heater A
P Pressure 4 High Alarm D Output Discharge B Heater B
R Ratio 5 Calibration F Input Feed C Level Sensor A
T Temperature 6 Sensor Failure I Internal D Level Sensor B
V Voltage 7 Unexpected
Non-Zero Value
M Power Supply E Hose
8 Unexpected
Zero Value
P Pneumatic Supply H Heater Hose
R Recirculation J Linear Sensor
9 Unstable K Reed Switch
C Communication A Loss P Display
D Pump A Runaway T Temperature
Control Module
D Cavitation X System
E Time-out
F Stall Up
G Stall Down
J Linear Sensor
K Reed Switch
M Maintenance A Pump
EValve
G Filter
Q Proportioning D Overdose
P Potlife
TDosing Time
