3 OPERATING INSTRUCTIONS
3.1 APC / SURGI-CHAIR SPECIFICATIONS
Info: All dimensions are specified in inches. Unless otherwise noted, all dimensions are ±.375.
Stacked dimensions are minimum (left) and maximum (right). GF Health Products, Inc.
reserves the right to change specifications without notice.
722
28.4
648
25.5
748
29.4
A
565
22.25 ±1.00
260
10.2
533
21.0
1129
44.5
521
20.5
891
35.1
450
17.7
38
1.5
160
6.3
E
679
26.7
7°
6
TRENDELENBERG
C
D
(TO BASE COVER)
B
509
20.0
431
17.0
DIMENSION
MODEL A B C D E
EPC250/ *
* pictured
EPD250
54.2/
62.45
72.7 25.9 21.3 33.2
ESC250/
ESD250
56.7/
64.95
75.0
56.5/
64.0
28.2 23.6 35.0
APC250
75.0 25.9 21.6 N/A
825/
/
32.5 ±1.0
Electrical Specications (Applies only
to EPC and ESC Models)
Product Classication: 1
Input Voltage: 120V~, ±5%, 60Hz
Amperage: Max. 2.7A
Duty Cycle: 5% 1 Min in 19 Min
IP Rating: IPX1
Grounding Protection: Type B
Electrical Specications (Applies only
to EPD and ESD Models)
Product Classication: 1
Input Voltage: 230V~, ±10%, 50/60Hz
Amperage: Max. 1.4A
Duty Cycle: 5% 1 Min in 19 Min
IP Rating: IPX1
Grounding Protection: Type B
