GM8136/GM8136S EVB User Guide
www.grain-media.com
13
Table 2-5. Pin Definitions of Series sensor interface connector
Pin No. Signal Name Pin No. Signal Name
1 3V3 2 3V3
3 DGND 4 DGND
5 NC 6 CAP_RST
7 NC 8 I2C_SDA
9 I2C_SCL 10 NC
11 CAP_CLKOUT 12 NC
13 NC 14 NC
15 DGND 16 NC
17 DN0 18 DP0
19 CKN 20 CKP
21 DN1 22 DP1
23 DGND 24 DGND
25 NC 26 NC
27 NC 28 NC
29 NC 30 NC
31 DGND 32 DGND
33 NC 34 NC
35 NC 36 NC
37 NC 38 NC
39 5 V 40 5 V
