GM8136/GM8136S EVB User Guide
www.grain-media.com
17
2.2 Description of Power Switch
Table 2-10. List of Power Switches on EVB
Legend Function
J13 This is 12V DC inlet, which connects to an external power adaptor.
SW7 Power source switch
2.3 Description of Push Buttons
Table 2-11. List of Push Buttons on EVB
Legend Function
PB1 ~ PB8 ADC0 keypads
2.4 Description of LED Indicators
Table 2-12. List of LED Indicators on EVB
Legend Function
LED1 5V Power source indicator
