2.1.4 Video output Interface Connector
The Video output interface connector (J8) provides a video output port for BT.656, BT.1120 and RGB565
interface. Please refer to Table 2-6 for the details.
Table 2-6. Pin Definition of Video output interface connector
Pin No. Signal Name Pin No. Signal Name
1 DGND 2 NC
3 TV_CLK 4 TV_VS/RGB_VS
5 DGND 6 TV_HS/RGB_HS
7 TV_DAT0/RGB_B3 8 3V3
9 TV_DAT1/RGB_B4 10 3V3
11 TV_DAT2/RGB_B5 12 3V3
13 TV_DAT3/RGB_B6 14 3V3
15 TV_DAT4/RGB_B7 16 I2S1_RXD
17 TV_DAT5/RGB_G2 18 DGND
19 TV_DAT6/RGB_G3 20 I2S1_SCLK
21 TV_DAT7/RGB_G4 22 I2S1_FS
23 TV_DAT8/RGB_G5 24 I2S1_TXD
25 TV_DAT9/RGB_G6 26 DGND
27 TV_DAT10/RGB_G7 28 NC
29 TV_DAT11/RGB_R3 30 DGND
31 TV_DAT12/RGB_R4 32 TV_RESET
33 TV_DAT13/RGB_R5 34 DGND
35 TV_DAT14/RGB_R6 36 I2C_SDA
37 TV_DAT15/RGB_R7 38 I2C_SCL
39 DGND 40 DGND
