Gram K3 - Page 36

36
The status byte is 63h (‘c‘)
63h – 20h = 43h ➔
Bit 7
Bit 6
(stable)
Bit 5
Bit 4
Bit 3
(no zero)
Bit 2
Bit 1
(Tare on)
Bit 0
(Gross)
0
1
0
0
0
0
1
1
The status byte is 6Ah (‘j‘)
6Ah – 20h = 4Ah ➔
Bit 7
Bit 6
(stable)
Bit 5
Bit 4
Bit 3
(zero)
Bit 2
Bit 1
(Tare on)
Bit 0
(Net)
0
1
0
0
1
0
1
0
The status byte is 6Bh (‘k‘)
6Ah – 20h = 4Ah ➔
Bit 7
Bit 6
(stable)
Bit 5
Bit 4
Bit 3
(zero)
Bit 2
Bit 1
(Tare on)
Bit 0
(Gross)
0
1
0
0
1
0
1
1
