140
Murphy Bed (Equipped on select XLS models)
Furniture
To Lower into a Bed:
1. PULL the back of sofa seat
toward you, flip, and fold down.
2. LOCATE the latch on the Upper
Right-Hand Side of the bed.
3. LIFT UP on the latch to release
the bed board. See Photo A, Left.
4. PULL the bed board toward you, then
• LOWER the bed board & mattress
to the horizontal position.
To Stow Away Bed, for Sofa Seat:
1. From the foot of the bed, LIFT up on the bed board, then
• PUSH forward until bed board & mattress are in the vertical position.
2. LIFT UP on the latch (found on the Upper Right-Hand Side)
3. Make sure the latch is properly aligned, then
• PUSH DOWN latch, sliding into the catch on the bed board until firmly secured.
See Photo B, Above.
4. LIFT the sofa seat back, flip, then PUSH into the upright position.
B.B.
A.A.
