Figure 3: Single Floor Building Deployment
Step 3: Placement of the Next Base Stations
Same procedure can be repeated again to determine best placement for next base station, users can mark
critical points on the edge of the site where the signal from first base station is weak, then place temporary
base stations in order to set intersection point of their coverage as the position for the next base station.
Areas marked with HS are (hotspots) and multiple base stations can be placed in these areas to provide
enough capacity for the subscribers.
Wide Area Scenario
When the cell coverage of the temporary base station doesn’t intersect with each other, users could place
first permanent base stations at the edges of the site while trying to have them (in a 45°) near to the center
of the site as much as possible, then mark next critical points which can be used to repeat the process
described above. Following figure illustrates this case.
