Grandstream Networks GDS370 Series User Manual

Description of the GDS370x
The below figures show the component of the back and front view of the GDS370x IP Audio Access Door System:
GDS3705
Figure 3: GDS3705 Front&Back View
GDS3702
Figure 4: GDS3702 Front&Back View
Connecting and Setting up the GDS370x
The GDS370x can be powered using PoE or PSU:
Using PoE as a power supply (Suggested)
Connect the other end of the RJ45 cable to the PoE switch.
A PoE injector can be used if the PoE switch is not available.
Using the power adapter as a power supply (PSU not provided)
Connect the other end of the RJ45 cable to the network switch or router.
Connect the DC 12V power source via the related cable to the corrected PIN of the GDS370x.
GDS370x Wiring Connection
Jack Signal Function Note

Grandstream Networks GDS370 Series Specifications

General

Brand	Grandstream Networks
Model	GDS370 Series
Category	Intercom System
Language	English
