Grandstream Networks GXP1625 Administration Guide

GXP16XX Administration Guide
Version 1.0.4.100
P a g e | 58
Phonebook  Phonebook Management
Enable Phonebook
XML Download
Configures to enable phonebook XML download. Users could select
HTTP/HTTPS/TFTP to download the phonebook file. The default setting is
"Disabled".
HTTP/HTTPS User
Name
Defines the user name for authentication within the HTTP/HTTPS server when
downloading the phonebook file.
HTTP/HTTPS
Password
Defines the password for authentication within the HTTP/HTTPS server when
downloading the phonebook file.
Phonebook XML
Server Path
Configures the server path to download the phonebook XML. This field could
be IP address or URL, with up to 256 characters.
Phonebook Download
Interval
Configures the phonebook download interval (in minutes). If it's set to 0, the
automatic download will be disabled. The default value is 0. The valid range is
5 to 720 minutes.
Remove Manually-
edited Entries on
Download
If set to "Yes", when XML phonebook is downloaded, the entries added
manually will be automatically removed. The default setting is "Yes".
Import Group Method
When set to "Replace", existing groups will be completely replaced by imported
one; When set to "Append", the imported groups will be attended with the
current one.
Sort Phonebook by
Sort the phonebook on the selection of first name or last name.
Download XML
Phonebook
Click on "Download" to download the XML phonebook file to local PC.
Upload XML
Phonebook
Click on "Upload" to upload local XML phonebook file to the phone.
Phonebook Key
Function
Controls the behavior of phonebook key. There are four options: Default, LDAP
Search, Local Phonebook, Local Group.
Phonebook  LDAP
LDAP protocol
Allows users to select LDAP or LDAPS protocol options. Default setting is
LDAP.
Server Address
Configures the IP address or DNS name of the LDAP server.
Port
Configures the LDAP server port.
Base
Configures the LDAP search base. This is the location in the directory where
the search is requested to begin.
Examples:
dc=grandstream, dc=com
ou=Boston, dc=grandstream, dc=com

Grandstream Networks GXP1625 Specifications

General

Brand	Grandstream Networks
Model	GXP1625
Category	IP Phone
Language	English
