CONFIGURATION GUIDE
The GXP1760/ GXP1780/ GXP1782 can be configured via two ways:
LCD Configuration Menu using the phone's keypad.
Web GUI embedded on the phone using PC's web browser.
Configuration Via Keypad
To configure the LCD menu using phone's keypad, follow the instructions below:
Enter MENU options: When the phone is in idle, press the round MENU button to enter the
configuration menu.
Navigate in the menu options: Press the arrow keys up/down/left/right to navigate in the menu options.
Enter/Confirm selection: Press the round MENU button or “Select” softkey to enter the selected option.
Back: Press “Back” softkey to exit to the previous menu.
Return to Home page: In any menu, press “Back” softkey to return to idle screen.
Note: The phone automatically exits MENU mode in these situations: An incoming call, when the phone is
off hook or the MENU mode if left idle for more than 60 seconds.
The MENU options are listed in the following table.
Table 4: Configuration Menu
Call History sub menu includes the following options:
Local Call Log.
Displays answered calls/dialed calls/missed calls/transferred calls.
Press “Clear All” to clear all local call history.
Broadsoft Call Log.
Displays Broadsoft call logs.
Status sub menu includes the following options:
Network status.
Displays the MAC address, IP information (DHCP/Static IP/PPPoE), IPv4
address, IPv6 address, Subnet Mask, Gateway and DNS server.
Account status.
Shows the registration status of each account.
System Status
Displays the hardware version, part number, software version, IP geographic
information and special features.
