GXP17xx Administration Guide
Defines the filename of the capture. Only required for USB.
Click to Start/ Stop and Download the packet capture.
Phonebook Page Definitions
Table 10: Phonebook Page Definitions
Specifies to which group the contact belong.
Specifies Contact’s First Name, Last Name, Phone Number, Accounts and Groups
to add one new contact in phonebook.
Deletes all contacts from phonebook.
Phonebook Group Management
Specifies Group’s name to add new group.
Phonebook Phonebook Management
Enable Phonebook
XML Download
Configures to enable phonebook XML download. Users could select
HTTP/HTTPS/TFTP to download the phonebook file. The default setting is
"Disabled".
The user name for the HTTP/HTTPS server.
The password for the HTTP/HTTPS server.
Phonebook XML
Server Path
Configures the server path to download the phonebook XML. This field could be
IP address or URL, with up to 256 characters.
Phonebook
Download Interval
Configures the phonebook download interval (in minutes). If it's set to 0, the
automatic download will be disabled. The default value is 0. The valid range is 5
to 720 minutes.
Remove Manually-
edited Entries on
Download
If set to "Yes", when XML phonebook is downloaded, the entries added manually
will be automatically removed. The default setting is "Yes".
Sort phonebook based on the selection of first name or last name. The default
setting is “Last Name”.
Click on "Download" to download the XML phonebook file to local PC.
Click on "Upload" to upload local XML phonebook file to the phone.
Control the behavior of phonebook key. There are five options: Default, LDAP
Search, Local Phonebook, Local Group, and Broadsoft Phonebook. The default
