o 802.1X
Enables/Disables 802.1X mode, Configures 802.1x identity and MD5
password.
o Layer 2 QoS
Configures LAN port 802.1Q/VLAN Tag and priority value. Select “Reset
Vlan Config” to reset VLAN configuration on the LAN port.
o PC Port Mode
Selects PC port mode (Enabled/Disabled/Mirrored). Configures PC port
802.1Q/VLAN Tag and priority value.
o OpenVPN Settings
Enable/Disable OpenVPN, configure OpenVPN server and port.
o IPv6 Settings
Selects IPv6 mode, Auto-configured or Statically configured (Full Static
/ Prefix Static).
Upgrade
o Firmware Server
Configures firmware server for upgrading the phone.
o Config Server
Configures config server for provisioning the phone.
o Config Upgrade Via
Allows users to choose the provisioning method: TFTP, HTTP or HTTPS
for configuration file download.
o Firmware upgrade via
Allows users to choose the firmware upgrade method: TFTP, HTTP or
HTTPS for firmware file download.
UCM Detect
Detect/connect UCM server to process auto-provision. Manually input
the IP and port of the UCM server phone wants to bind with, or select
from the available UCM server in network.
Factory Functions
o Audio Loopback
Speak to the phone using speaker/handset/headset. If you can hear
your voice, your audio is working fine. Press “Exit” softkey to exit audio
loopback mode.
o Diagnostic Mode
All LEDs will light up. Toggle the line keys LED color to green with “#”
