GXP17xx Administration Guide
DNS Server 2
Enter the DNS Server 2 for IPv6.
Preferred DNS
server
Enter the Preferred DNS Server for IPv6.
Network  Advanced Settings
802.1X mode
Allows the user to enable/disable 802.1X mode on the phone. The default value
is disabled. To enable 802.1X mode, this field should be set to EAP-MD5, users
may also choose EAP-TLS, or EAP-PEAP.
802.1X Identity
Enter the Identity information for the 802.1x mode.
MD5 Password
Enter the MD5 Password for the 802.1X mode.
802.1X CA
Certificate
Upload 802.1X CA certificate to the phone, or delete existed 802.1X CA certificate
from the phone.
802.1X Client
Certificate
Upload 802.1X Client certificate to the phone, or delete existed 802.1X Client
certificate from the phone.
HTTP Proxy
Specifies the HTTP proxy URL for the phone to send packets to. The proxy server
will act as an intermediary to route the packets to the destination.
HTTPS Proxy
Specifies the HTTPS proxy URL for the phone to send packets to. The proxy
server will act as an intermediary to route the packets to the destination.
Layer 3 QoS for SIP
Defines the Layer 3 QoS parameter for SIP. This value is used for IP Precedence,
Diff-Serv or MPLS. The default value is 26.
Layer 3 QoS for RTP
Defines the Layer 3 QoS parameter for RTP. This value is used for IP Precedence,
Diff-Serv or MPLS. The default value is 46.
Layer 2 QoS
802.1Q/VLAN Tag
Assigns the VLAN Tag of the Layer 2 QoS packets. The default value is 0.
Layer 2 QoS 802.1p
Priority Value
Assigns the priority value of the Layer2 QoS packets. The default value is 0.
PC Port Mode
Configures the PC port mode. When set to “Mirrored”, the traffic in the LAN port
will go through PC port as well and packets can be captured by connecting a PC
to the PC port. The default setting is “Enabled”.
PC Port VLAN Tag
Assigns the VLAN Tag of the PC port. The default value is “0”.
PC Port Priority
Value
Assigns the priority value of the PC port. The default value is “0”.
Enable DHCP VLAN
Enable / Disable auto configure for VLAN settings through DHCP.
Enable LLDP
Control LLDP (Link Layer Discovery Protocol) service. Default setting is “Enabled”.
Network  OpenVPN Settings
OpenVPN Enable
Enable/Disable OpenVPN feature. Default is No.
OpenVPN Server
Address
Specify the IP address or FQDN for the OpenVPN Server.
OpenVPN Port
Specify the listening port of the OpenVPN server. Default is 1194.
