Grant SUB - Page 7

SUB Universal, SBB boiling, JB and PB unstirred water baths
Part No. 15133/Issue 14 Page 7 January 2010
SUB
Set/over temperature
cut-out knob
Ventilation slots (front and rear)
Bath/set
temperature
display
Fuse drawer
Mains voltage
supply connection
ON/OFF
switch
Display
set temp
Set temp
Alarm
lamp
Heater
lamp
SBB
Ventilation slots (front and rear)
ON/OFF switch
Energy regulation
control
Heater lamp
Over temperature
cut-out reset buttons
Mains voltage supply
connection
Fuse drawer
JB
Heater lamp
ON/OFF
switch
Set temp control
knob
