With this RSSI signal and a flight control board with OSD, e.g. No.
48377, the signal strength of the receiver can be displayed in video
goggles or monitors.
Adjustment range: OFF, CH8, CH12, CH16
F.RESET
After changing the value field to "Yes" and then pressing or tapping
on the ENT key, or equivalent, a factory reset of the receiver is per-
formed.
Display "MIXER"
RX FREE MIXER
MASTER CH: 0
SLAVE CH: 0
TRAVEL–: 100%
TRAVEL+: 100%
MIXER: 1
TRIM: 0%
Up to five mixers can be programmed in the receiver.
MIXER
In the "MIXER" line, select one of mixers 1 … 5.
The following settings in this display only relate to the mixers selected
in the "MIXER" line.
MASTER CH
In this line the MASTER CH (signal source or source channel) has to
be selected.
Selection range: (CH)1 … (CH)6
If no mixer has to be set, select "0".
SLAVE CH
In this line, select the SLAVE CH (signal source or source channel) to
which the signal of the MASTER CH (source channel) is proportion-
ally mixed.
The level of mixing is determined by the percentages entered in the
"TRAVEL–" and "TRAVEL+" lines.
Selection range: (CH)1 … (CH)6
If no mixer has to be set, select "0".
TRIM
Analogous to the trimming of the control functions 1 ... 4, the neu-
tral position of the mixer in the range of ± 30% can be trimmed in
this line.
TRAVEL –/+
With the settings of these two lines, the percentage of mixing is
specified in relation to the MASTER signal separately for both direc-
tions.
Display "CH REVERSE"
CH REVERSE
CH2 : Normal
CH3 : Normal
CH5 : Normal
CH6 : Normal
CH1 : Normal
CH4 : Normal
In this display, the direction of rotation of each of the servos con-
nected to the receiver outputs 1 ... 6 can be set individually: select
the desired line; press or tap on the ENTER key or equivalent, then
change the setting value from "Normal" to "Reverse" or vice versa in
the active value field.
