GRAUPNER GR-12L HoTT User Manual

6 / 20 7 / 20
S1012_GR-12L_DE_V1sh S1012_GR-12L_DE_V1sh
Technical data
S1012 GR-12L HoTT
Antenna
1 x wire 145 mm
of which Antenna 30 mm
Operating voltage (2.5) 3.6 ... 8.4 V
Frequency range 2400 ... 2483.5 MHz
Modulation 2.4 GHz FHSS
Number of controls 6
Current consumption approx. 70 mAh
Temperature range -15 … +70°C
Dimensions approx. 36 x 21 x 10 mm
Weight approx. 7 g
Connection table
CH 5 SERVO and updates / SENSOR / BATT-V
CH6 SERVO / SUMD / SBUS / SP2048
Symbol description
Always observe the information indicated by these warning signs.
Particularly those which are additionally marked with the words
CAUTION or WARNING.
!
The signal word WARNING indicates the potential for serious injury,
the signal word CAUTION indicates possibility of lighter injuries.
The signal word Note indicates potential malfunctions.
Attention indicates potential damages to objects.
Safety notes
!
These safety instructions are intended not only to protect the prod-
uct, but also for your own and other people’s safety. Therefore please
read this section very carefully before using the product!
• Do not leave the packaging material lying around, this could be a
dangerous toy for children.
• Persons, including children, with reduced physical, sensory or
mental capabilities, or lack of experience or knowledge, or not
capable to use safely the receiver must not use the receiver with-
out supervision or instruction by a responsible person.
• Operation and use of radio-controlled models needs to be learnt!
If you have never driven such a model, then start extra carefully
and make sure to be familiar with the reactions of the model to
the remote control commands. Proceed responsibly.
• First, always perform a range and function test on the ground (to
do so, hold your model tight), before you use your model. Repeat
the test with running motor and with short throttle bursts.
• Only use the components and spare parts that we recommend.
Always use matching, original Graupner plug-in connections of
the same design and material.
• Make sure that all of the plug-in connections are tight. When dis-
connecting the plug-in connections, do not pull the cables.
• Protect the receiver from dust, dirt, moisture and foreign parts.
It must be protected from vibration as well as excessive heat or
cold. The models may only be operated remotely in normal out-
side temperatures such as from -10°C to +55°C.
• Always use all your HoTT components only with the latest firm-
ware version.
• If you have questions which cannot be answered by the operat-
ing manual, please contact us or another expert in the field.
