SUMD SUMDIN
GR-16 HoTT and GR-24 HoTT CH8 CH7
GR-32 HoTT S CH7
Connection 8
CH OUTPUT TYPE
Depending on the settings in the "CH OUTPUT TYPE" line of the "RX
SERVO TEST" page of the telemetry menu, the output 8 can be used
for different scopes. Carry out the changeover as described in the
instructions for the transmitter or the SMART-BOX.
By setting ...
• ONCE or SAME
to connect a servo, ESC, Gyro, etc...
ശ ONCE
The servo connections of the receiver are actuated sequen-
tially. The receiver power supply is less stressed.
ശ SAME
The servo connections of the receiver are actuated in a 4 pcs
block synchronic. The simultaneous start-up of up to four ser-
vos has a noticeably higher load on the receiver power sup-
ply.
• SUMO, SUMI, SUMD, SUMD3 or SBUS
to connect a sum signal cable
ശ SUMO
PPM modulated sum signal “OUT“ of the control channel 04
to max. 16.
ശ SUMI
Sum signal "IN" in case of satellite receiver
ശ SUMD
Digital sum signal of the control channel 04 to max. 16.
HD: Hold the last servo position in case of Fail-Safe
FS: Moving to the programmed positions in case of Fail-Safe
OF: (OFF) switch-off of the SUMD signal in case of Fail-Safe
ശ SUMD3
Digital sum signal adapted to the transmitter mz-32 HoTT for
the transmission of 32 control channels including their digital
switches.
ശ SBUS
Digital sum signal in SBUS format.
RX SERVO TESTV7.07
ALL–MIN : 1000µsec
ALL–MAX : 2000µsec
ALARM VOLT : 3.8V
TEST : STOP
ALARM TEMP–:–10°C
ALARM TEMP+: 55°C
CH OUTPUT TYPE:ONCE
