Setting and display of the receiver settings
The receiver-side menus can be viewed and sometimes changed
using a suitable HoTT transmitter or the SMART-BOX. You can find
out how to open the menus of a receiver in the "Telemetry" section
of the corresponding manual as well as a detailed description of the
receiver menus on the respective product page at www.graupner.
de on the Internet.
Special features of the GR-12 HoTT receiver
Connection 5
To the "– + 5 T" marked port it is possible to connect not only RC
components but also telemetry modules. Accordingly, select in the
line "5CH FUNCTION" of the page "RX CURVE" of the telemetry menu
"SERVO" or "SENSOR". Carry out the changeover as described in the
instructions for the transmitter or the SMART-BOX.
Connection 6
Depending on the settings in the "CH OUTPUT TYPE" line of the "RX
SERVO TEST" page of the telemetry menu, the output 6 can be used
for different scopes. Carry out the changeover as described in the
instructions for the transmitter or the SMART-BOX.
By setting ...
• ONCE or SAME
to connect a servo, ESC, Gyro, etc...
ശ ONCE
The servo connections of the receiver are actuated sequen-
tially. The receiver power supply is less stressed.
ശ SAME
The servo connections of the receiver are actuated in a 4 pcs
block synchronic. The simultaneous start-up of up to four ser-
vos has a noticeably higher load on the receiver power sup-
ply.
• SUMO, SUMI, SUMD, SUMD3 or SBUS
to connect a sum signal cable
ശ SUMO
PPM modulated sum signal “OUT“ of the control channel 04
to max. 16.
ശ SUMI
Sum signal "IN" in case of satellite receiver
TELEMETRY
SETTING & DATA VIEW
SENSOR
RF STATUS DISPLAY
SELECT ANNOUNCE
RX DATA ON
ALARM SETTING
RX CURVE V7.07
TYPE : B
CURVE1 CH : 02
TYPE : B
CURVE2 CH : 03
TYPE : B
CURVE3 CH : 04
5CH FUNCTION:SERVO
RX SERVO TESTV7.07
ALL–MIN : 1000µsec
ALL–MAX : 2000µsec
ALARM VOLT : 3.8V
TEST : STOP
ALARM TEMP–:–10°C
ALARM TEMP+: 55°C
CH OUTPUT TYPE:ONCE
To Next Page
