Connection example
… for electric driven models
red wire of the voltage sensor
Baery connecon
Motor connecon
E.S.C.
ON/OFF switch
Temperature sensor
Steering servo
CH 1
CH 2
Temp. /
voltage
sensor
CH 4
CH 3
Receiver
… for model with I.C. engine
CH 1
CH 2
Baery
Steering servo
Throle servo
Receiver power supply
Aach temperature
sensor to cylinder head
Temp. /
voltage
Sensor
Receiver
