Battery charging process
Plug the connection cable to a power source: 110/240V.
The LEDs will be green.
Plug the battery balancer connector into the related charger
socket (3 S).
The LEDs will turn from green (stand by mode) to red (charge
mode).
The LEDs will turn green depending on the charge state of the
single cells. When all the LEDs will turn from red to green, then
the charge is complete.
Disconnect the battery from the charger and then the AC char-
ger cable.
Preparation before use
To start using the transmitter you have to read the HoTT MZ-12
transmitter manual.
Battery installation
Fix the battery in its compartment using some hook-and-loop
tape. Place the battery so that the copter’s center of gravity is in
the middle of the frame.
Binding receiver and transmitter
Transmitter and receiver are already bound by the factory. In
case you wanted to repeat the binding process, go on as fol-
lows:
Switch the transmitter’s RF section off in the “Basic model
settings” menu (see transmitter manual)
Switch on the receiver and put it in binding mode, by press-
ing and holding the binding button (green and red LED on
the receiver are flashing)
Initiate binding in the transmitter’s “Basic model settings”
menu.
If the red LED of the receiver goes out within about 10 sec-
onds and the green LED is illuminated, the binding process
has been completed successfully. Your transmitter/receiver
combination is now ready for operation.
If the red LED is still lit, the "binding“ failed. In this case,
repeat the whole procedure.
The binding process is also described in the transmitter and
receiver manuals.
