Using camera / transmitter
Camera and transmitter are assembled and connected.
Scan the transmitter's frequency in your suitable optional video
goggle or video monitor.
The video signal transmission begins as soon as the battery is
connected. The channel of the transmitter is factory set to chan-
nel 01.
If you want to change the transmitting channel of the transmit-
ter, proceed as follows: Set the micro-switch bar on the trans-
mitter circuit board according to the included manual for the
desired channel.
Video transmitter technical data
No. S8460
Operating voltage DC (V): 7 - 22,2 (3S LiPo)
Width [mm]: 24
Height [mm]: 12
Length [mm]: 35
Frequency GHz: 5,8
Channels: 22
Output mW: 25
Weight [g]: 12
Receiver settings
The transmitter is already completely set for HoTT Hornet 250. If
you want to change however some settings, follows the instruc-
tions content in the receiver manual.
First flight
Switch the transmitter on and plug the battery to prepare the
HoTT Hornet to fly.
Unfold the arms completely and make sure they are in the cor-
rect position.
Choose a free area for your first flight. Select first always the Atti-
tude mode because so the copter is easier to control. Take firstly
confidence with the flight attitude of the HoTT Hornet. Proceed
carefully and responsibly.
The included Voltage module with SBEC offers you the possibility
to set up to three different voltage alarms in steps of 0,1 V. Thus
read the manual of the module and of your HoTT mz-12 trans-
mitter.
