Initialization of the gyro in the receiver
Once the model has been switched on, the gyro immediately
becomes active but still needs to be initialized. To initialize the
gyro, keep your model still when you switch it on. The calibra-
tion process can only be performed when the receiver is abso-
lutely still.
After 3 seconds in still position you will hear beeps emitted by
all motors. The signal tone can vary depending on the esc model.
These "wiggles" signal that initialization has been successful and
that calibration is complete. Always wait until the calibration pro-
cess has finished before starting to fly the model. The motors
will not start until the calibration is complete.
Installing the propellers
Warning
Risk of injury by rotating propellers in case the motors start.
Always unplug the XT-60 connector to the LiPo battery before
working on the propellers.
Install the propellers as shown in the picture below. Pay atten-
tion to install the proper propeller to each motor. The propeller
rotation sense is written on the propeller (R/L)! The image rep-
resents the copter seen from the top.
Pos. 1 - 1348.6x3 R C-Prop yellow
Pos. 2- 1348.6x3 L C-Prop yellow
Pos. 3 - 1348.6x3 L C-Prop red
