GRAUPNER Husky 1800S - Technical Data; Recommended Accessories

19 / 76
13410_13410.100_HU_V.1
Technical data
Husky 1800S
Wingspan approx. 1800 mm
Length approx. 1200 mm
Overall height approx. 340 mm
All-up weight, approx. 2500 g
Operating voltage max. 16.8 V
Battery dimension max. 37 x 35 x 150 mm
Recommended battery capacity 2200 - 3000 mAh
Servo operating voltage 4,8-6 V DC
Receiver channels min. 7
Speed controller 40 A
NOTE
The technical data of the optional receiver are available in the
manual included in the receiver package content.
Recommended accessories
No 13410.100
Pcs. Description No.
1 Receiver GR-16 HOTT 33508
1 LiPo 4/2200 14,8V 78122.4
1 mx-16 33116.77
1 DES 488 BB MG 7919
1 Husky 1800S ski set 13410.43
1 Husky 1800 floaters set 13410.44
Additional to No 13410
Pcs. Description No.
1 Motor 13410.81
1 BRUSHLESS CONTROL + T 45
XT-60
33745.XT60
1 Servo extension cables 0,3
qmm, 200 mm
S8170
2 DES 587 BB MG 7932
5 DES 488 BB MG 7919
