Speed controller of No.13410
Speed controller technical data
Weight incl. leads 48 g
EMK brake Programmable
Continuous current at 25°C 40 A
Peak power consumption 10 sec. 55 A
Cell count LiPo, Lilo: 2 - 4
Operating voltage 7,4 - 16,8 V
Dimensions approx. 65 x 25 x 12 mm
BEC receiver current supply: 5 V / 4 A
Servo operating voltage 4,8 - 6 V DC
Servos max. 5
Speed controller 40 A
Maximum motor RPM 2 poles 210000 RPM
Maximum motor RPM 6 poles 70000 RPM
Maximum motor RPM 12 poles 35000 RPM
Automatic under-voltage cut-off YES
Automatic thermal protection 110 °C
Automatic motor reduction if signal is lost YES
Commissioning the speed controller
NOTE
The speed controller can be operated with different transmitters
from different manufacturers, in order to ensure optimal opera-
tion, it is therefore necessary to adjust the controller to your trans-
mitter.
Programming the controller to your throttle stick
1. Move the throttle stick to the full throttle position and connect
the drive battery, the motor plays the melody "Do Re Mi".
2. After 2 seconds the motor beeps with 2 long sounds (B-- B--)
then the controller has detected the full throttle position. Move
the throttle stick to the stop position within the next 2 seconds
after the sounds (B-- B--), then the controller has detected the
stop position.
3. After a long (B--) the setting is completed and the controller is
ready to start.
