12 Remote control set description
Binding of any number of receivers to the channel •
expansion (32 channels maximum)
As many as four servos can be controlled •
simultaneously as a block in the SAME
operating
mode with a servo cycle time of 10 ms (digital
servos only).
Thanks to cycle time reduced down to as little •
as 10 ms, extremely short response times are
achieved.
Real-time telemetry evaluation in the transmitter •
display Additionally, telemetry data can also be
selectively displayed by the SMART-BOX.
Additional HoTT features of the mc-32
Super-fast response time through use of a fast •
main processor for data transmission.
Micro-SD card for storage of telemetry data and •
for additional functions
Obsolescence-proof through update capability over •
USB interface as well as via the micro-SD card
The included Lilo battery (changes reserved) •
has a capacity of over 6000 mAh. This makes
extremely long fl ight times possible and also
reduces the number of charging repetitions.
Modulation changeover per software: e.g. from •
"EXT. PPM" (e.g. Weatronic) to HoTT at the press
of a button.
Swashplate limiting: This function limits the •
swashplate's tilt angle to prevent the potential for
mechanical collision in helicopter 3D operation at
full-limit roll and pitch-axis
Ring-limiter: • functions similar to swashplate
limitation but is used for control of up to three
Voith-Schneider drives in ship models
Channel sequencer for automating servo motion •
sequences of up to three servos, e.g. to automate
the lowering of landing gear or to extend/retract
drives in self-launching gliders
Multi-channel function for operating • Graupner
product line NAUTIC modules
Digital trimming with pseudo »analog« endless •
pinions, effective per specifi c fl ight-phase
Auto-trim function. The current joystick positions •
for trimming fi xed-wing or helicopter models will
be stored in trim memory at the press of a button.
(Model »compensation«, activate switch and
release joystick. The correction will be blended in
»gently« upon return of the joystick.
C1 changeover, brake/elec. motor: This •
changeover can be implemented very easily via
enhanced fl ight phase programming. The pilot
determines the joystick positions (forward/rear) at
which the motor is to switched off or the airbrakes
are to be retracted.
16 control functions maximum•
Simplifi ed arrangement of operating elements, •
such as joysticks, external switches, proportional
controls and trim levers as control functions
Protection against obsolescence is provided •
by virtue of a fast 32-bit operating system with
modern fl ash memory that can be updated.
Blue back-lighted MULTI-DATA-GRAPHIK-LCD •
monitor with signifi cantly better legibility under
unfavorable light conditions
CONVENIENCE MODE SELECTOR to simplify •
changeovers between operating modes 1 … 4
(e.g. throttle left/throttle right)
Two freely programmable mixers for fi xed-wing •
or helicopter models, each with freely selectable
input and output functions; four curve mixers
with innovative 8-point curve technology for
easy to set and adjust curve values at up to
eight points for throttle, pitch, tail or other non-
linear characteristics. The arithmetic unit in the
CPU employs an ingenious method of calculating
polynomial approximations for truly-rounded, ideal
MPC (multi-point curve) mixer curves
Computer System mc-32
32 channel remote control set in 2.4 GHz Graupner-HoTT technology
(Hopping Telemetry Transmission)
Shifting curve mixer points can be done along •
both axes with the CAP touch pad keys
Eight fl ight-phase programs can be individually •
adapted for each model and given a name. The
switchover time is programmable separately.
SUPER SERVO menu with a perfect overview •
of all servo setting data and simple parameter
correction at four "levels": direction of rotation,
mid-point setting, separate servo travel on both
sides and separate travel limiting on both sides for
16 servos with a total of 96 setting options
SUPER-DUAL-RATE, EXPO and EXPO/DUAL-•
RATE menu with 36 potential setting variants for
three servo functions and six fl ight phases
Practice-optimized multi-function menu for •
aerofoils and helicopter models. Entry of the
number of aileron and fl ap servos automatically
programs all necessary mixer functions in the
multi-function "Wing mixers" menu. Differential
aileron mixer, butterfl y mixer, dual-fl ap mixer,
automatic gyro set function and other special
functions
Helicopter swashplate mixer for 1, 2, 3, or 4 point •
steering.
Selectable cycle time: 10 ms or 20 ms/30 ms, •
depending on receiver and operating mode
A convenient timers menu with a system of eight •
stopwatches, alarm timer, countdown timer, laps
counter and so on. Two running timers and one
lap timer can be displayed at the same time in
large characters.
Stopwatch with history: In addition to the lap •
counter there is a "Time 1" which captures the
switch-on time and a "Time 2" which records the
ON and OFF times separately
Channel mapping• in the receiver allows free
distribution of control functions.
The travel distance and rotation direction settings •
