GRAUPNER mc-32

87
Detail program description - Base setup models | Winged models
as the opportunity to distribute the transmitter's 16
control channels across as many as four receivers.
This redistribution is subsequently referred to as
"mapping" or "channel mapping" (channel correlation).
Select the receiver to be "mapped" with the selection
keys of the left or right touch pad then tap briefl y on
the center
SET key of the right touch pad.
Channel mapping within a receiver
Analogous to the channel correlation function in
the »Telemetry« menu on page 232, described as
"Channel Mapping", it is very simple to use this menu
item to freely assign the transmitter's control channels
present on the receiver's inputs to any specifi c
receiver outputs (servo connections) for the bound
receiver designated by the column labeled BD1.
RECEIVER CHANNEL MAP BIND1
Rx Input Ch 1
Rx Input Ch 2
Rx Input Ch 3
Rx Input Ch 4
Rx Output Ch 1
Rx Output Ch 2
Rx Output Ch 3
Rx Output Ch 4
After selection of the desired output with the selection
keys of the left or right touch pad, the respective
input fi eld will be framed. Briefl y tap the center SET
key of the right touch pad: The current setting will be
displayed in inverse video. Now use the selection
keys of the right touch pad to select the desired input
channel's respective transmitter output, see page 218.
Note:
The number of lines available in the list (outputs)
corresponds to the maximum number of servos which
can be attached to the given receiver.
BUT CAUTION: If you wish to operate two servos
with one control function, for example such as
transmitter control function 2 (roll) which is divided
up into control channels 1 & 2 for left and right roll
servos for the "3Sv(2Roll)" option in the »Heli type«
menu; then "map" the corresponding transmitter
outputs, in this case for channels 1 & 2 (= inputs to
the receiver) accordingly.
Important notice:
The
mc-32 HoTT transmitter's »Tx. output swap«
option permits the transmitter's 16 control functions
to be freely swapped in a similar manner or even
permits multiple outputs to be assigned to the same
control function. To keep controls manageable,
however, we strongly recommend using only one of
the options at a time.
Channel assignment on other receivers
As already mentioned, the "Rcv Ch map" menu
option can be used to freely distribute the mc-32
HoTT transmitter's 16 control channels across up
to four receivers, whereby the numbering of outputs
(servo connections) as well as the maximum number
of available lines (outputs) will correspond to the
maximum number of servo connections available on
the given receiver.
RECEIVER CHANNEL MAP BIND2
Rx Input Ch 16
Rx Input Ch 16
Rx Input Ch 16
Rx Input Ch 16
Rx Output Ch 1
Rx Output Ch 2
Rx Output Ch 3
Rx Output Ch 4
After selection of the desired output with the selection
keys of the left or right touch pad, the respective input
fi eld will be framed. Tap the center SET key of the
right touch pad. The current setting will be displayed
in inverse video. Now select the desired input
channel with the selection keys of the right touch pad.
For example, appropriate for the above example with
roll servos:
RECEIVER CHANNEL MAP BIND2
Rx Input Ch 1
Rx Input Ch 2
Rx Input Ch 16
Rx Input Ch 16
Rx Output Ch 1
Rx Output Ch 2
Rx Output Ch 3
Rx Output Ch 4
Note:
The number of lines available in the list (outputs)
corresponds to the maximum number of servos which
can be attached to the given receiver.
RF transmit
This menu line provides an option for manually
switching the transmitter's RF transmission on and
off to specifi c models while the transmitter is in
operation. For example, to save power while a model
is being programmed. If this line option was set to
OFF, it will be canceled (i.e. set to ON) the next
time the transmitter is switched on.
If necessary, use the  selection keys of the left or
right touch pad to switch to the "RF module" line then,
with a brief tap on the center SET key of the right
touch pad, activate the value window:
Stick mode
Module
1
bind
bind
n/a
n/a
HoTT
SET SET SEL SET
Rcv Ch Map R16 R08
n/a
n/a
RF transmit on
BASIC SETTING,MODEL
The right selection keys can now be used to choose
between OFF and ON. Another tap on the center SET
key of the right touch pad will conclude the entry.
