Description of radio control set
mx-10 Computer System
Five-channel radio control set with Graupner HoTT 2.4 GHz technology (Hopping Telemetry Transmission)
Graupner HoTT technology offers excellent reliabi-
lity in use, with bi-directional communication bet-
ween transmitter and receiver, integrated telemetry
(with the optional Smart-Box) and ultra-fast respon-
se times.
Simplifi ed programming technology with „Jumpers“.
Micro-computer radio control system exploiting the •
latest Graupner HoTT 2.4 GHz technology
Bi-directional communication between transmitter •
and receiver
Ultra-fast response times through direct, ultra-reliable •
data transmission from the main processor to the 2.4
GHz RF module.
Telemetry menu (with the optional Smart-Box) for •
displaying telemetry data, and programming receiver
outputs and optional sensors.
Short, folding aerial•
Easy programming and accurate setting with toggle •
switches and a switch key
3 switches: a three-position switch for Trainer/pupil-•
mode, 2 two-position switches for dual rate and
channel 5 are already built
5 control functions, including 1 switching channel•
Servo reverse•
Mode selector for simple switching between stick •
MODES 1 ... 4 (throttle left / right, etc.) All applicable
settings are automatically converted.
Wing menu: 1 Ail, 2 Ail, V-tail, delta/fl ying wing•
The following settings can only be done via the optional
Smart-Box:
User-selectable servo cycle times for digital servos, •
min. 10 ms
Servo-control ± 150% for all servo outputs can be set •
separately for each side (Single Side Servo Throw)
Sub-trim in the range of ± 125% to adjust the neutral •
position of all servos
General features of the HoTT system
Simple, ultra-fast binding of transmitter and receiver•
Multiple receivers can be bound per model for paral-•
lel operation
Extremely fast re-binding, even at maximum range•
Two-receiver satellite operation using special cable •
connection
