Description of transmitter
Description of transmitter
Transmitter controls
Attaching the transmitter neckstrap
You will fi nd a strap lug mounted in the centre of the
front face of the mx-10 HoTT transmitter, as shown in
the drawing on the right. This lug is positioned in such a
way that the transmitter is perfectly balanced even when
suspended from a neckstrap.
Order No. 1121 Neckstrap, 20 mm wide
Order No. 70 Neckstrap, 30 mm wide
Aerial with folding / rotating base
3-position switch
Mode: Pupil / Teacher /
normal
2-position switch
Channel 5
left hand stick
Tr im
ON / OFF switch
Tr im
Right-hand stick
2-position switch
Dual Rate
Carry handle
Neckstrap lug
Central Status LED
Servoreverse switch
Wing mixer
Channel 1 - 5
BIND-Button
