◎ CHARGER CONTROL IDENTIFICATION
① Mini USB ④
3.0”TFT LCD W/Touch Screen
⑦
Charge/discharge status LED bar
⑩
Temperature sensor port
⑬
Motor sensor
② DC Input
⑤
LED Indicator for Charge/ discharge
⑧
Battery socket
⑪
USB +5V 2.5A
⑭ Servo test
③ Fan ⑥
Channel selection button
⑨ Balance port
⑫
EXT Module
①
④
⑤
⑥
⑦
⑧
⑪
⑫
⑬
⑭
⑨
⑩
②
③
TOP FRONTBACK RIGHT
