17 18
< NORMAL >
NiCd/NiMH :
The charger will charge the pack with the preset charge current, but will stop charging
every minute to calculate voltage and detect Delta peak. This allows for better peak detection so it
is better to for the time worn battery and unstable charge cable
< LINEAR >
NiCd/NiMH :
The charger will charge the pack with the preset charge current and detect Delta peak
every second without stopping to charge. Since changing the charge cable contact point might
terminate charging, make sure not to touch charge cable during charging. The charger will stop
charging for a few seconds in 10 minutes to calculate the internal resistance. This method allows to
detect ZEROpk (0mV/cell) and terminate without temperature rise
< CC/CV >
LiIon/LiPo/LiFe/Pb :
The charger will charge the pack with the preset charge current and detect
Delta peak every second without stopping to charge. Since changing the charge cable contact point
might terminate charging, make sure not to touch charge cable during charging. The charger will
stop charging for a few seconds in 10 minutes to calculate the internal resistance. This method
allows to detect ZEROpk (0mV/cell) and terminate without temperature rise
< FAST >
LiIon/LiPo/LiFe :
The charge will charge the pack with constant current after constant voltage
charging The calculated voltage from balance cable is used to control so the pack can be charged
safely (Only the battery equipped with balance cable should be charged, excluding Pb battery)
< STORE >
LiIon/LiPo/LiFe :
The charge will charge/discharge to store the pack with constant voltage after
constant current charging/discharging. CC/CV is applied to N-STORE and FAST is applied to
Q-STORE
Charge mode of POLARON EX CHARGER
CC-CV : Normal charge
FAST : Fast charge
N-STORE : Normal store charge
Q-STORE : Quick store charge
CV-LINK :
The packs that has the same number of cells and capacity
can be charged simultaneously
(If the cells are different, error is occurred)
AUTO :
The charge will automatically adjust the charging condition
NORMAL : Normal charge
LINEAR :
The preset current is maintained throughout the charge.
CC-CV : Normal charge
In CV-LINK mode, the packs should have the same voltage, capacity and number of cells.
Since the charging parameter is different, it causes the damage to batteries.
Please install balance cable to CH1, CH2
This page shows the process of battery check when the
balancer is connected. The next page is accessed
automatically When to tap Enter button the charger
initiates to charge immediately
When to connect balance board, the charger can only check the
number of cells. If the confirmed number of cells is not correct,
tap ESC button to get back to the previous page and check the
parameters again. If the number of cells is correct, the next page
is accessed automatically. When to be initiated without balance
board, it is activated for you to check and decide the number of
cells. When to tap Enter button, the charger initiates to
charge immediately
(This page doesn’t appear when NiCd, NiMH batteries is connected)
Number of cells checking
LiPo, LiIon, LiFe
NiCd, NiMH
Pb
Battery Cell Checking
To Next Page
