Pressing the STOP button will cause the pop-up window
to appear, asking for a confimation that you want to stop
the operation. Tapping either the STOP or ESC button will
cause the charger to either stop or continue the cycle,
respectively.
◎ BALANCE PAGE
◎ DATA VIEW PAGE
Tapping the BALANCE icon on the main page will access the balance mode. Tap the DEC/INC Buttons
to toggle between the 3 modes. Tap the Enter button to initiate the balancing process. The selected
mode is used with the batteries that are equipped with a cell balance connector (LiPo, LiIon, LiFe
batteries).
Tap the BALANCE icon to access the balance
mode.
(The balance connector should be installed.)
Tap the DATA icon to check the charge/discharge
data on the main page.
LiPo, Lilon, LiFe battery balance page
This page (left) displays the connected battery parame-
ters.
Tapping will activate the box (blue). The battery memory
can then be selected.
BALANCE MODE 1 BALANCE MODE 2
▲ ▲ ▲
Tap the DATA icon on the main page to access the data view mode. There are 3 view modes. After
activating the buttons, the data can be programmed by tapping the DEC/INC buttons. In the Cycle data
and Graph data modes, the data can be accessed. In the Normal data mode, the parameters can not
be programmed.
BALANCE MODE 3
1) BALANCE MODE 1 : This page (above, left) shows the basic date of the battery.
2) BALANCE MODE 2 : This page (above, center) shows the cell voltage and internal
impedance values.
3) BALANCE MODE 3 : This page (above, right) displays multiple parameters.
- Center Voltage(Vc): The voltage of the center in the Y axis.
- Range Voltage(Vr) : The voltage range of every section in the Y axis
- Manual / Auto
Manual:
The graph can be manually operated. Tap the data box to activate. Tap the DEC/INC
buttons to program the parameters. The Center Voltage and Range Voltage can
be activated and programmed using the manual setup.
Auto:
This mode performs an automatic setup of the graph for the operation.
Each cell voltage is activated and checked.
- Cell Voltage :
Displays the cell voltage. Tapping activates this paramter, allowing the cell data to
be checked.
Center voltage
Range voltage
Cell Voltage
Manual / Auto
USER NAME
USER NAME
To Next Page
