◎ CHARGER CONTROL IDENTIFICATION
① Mini USB ④
3.0”TFT LCD with Touch Screen
⑦
Charge / discharge status LED bar
⑩
Temperature sensor port
⑬
Motor sensor
② DC Input
⑤
LED Indicator for charge / discharge
⑧
Battery socket
⑪
USB +5V 2.5A
⑭ Servo test
③ Dynamic Cooling Fan
W/Speed control
⑥
Channel selection button
⑨ Balance port
⑫
Ext. Module / Speed Controller
Setting
①
④
⑤
⑥
⑦
⑧
⑪
⑫
⑬
⑭
⑨
⑩
②
③
TOP FRONTBACK RIGHT
