18
lower current. The capacity limit TCS CAPACITY (10 - 100%; default setting 100%) generates an audible alert at the selected percentage; the charger
purposes, you can halt the charge process at that point, and enjoy much shorter charge times.
TCS response TCS END ACTION
reacts: continue charging or stop the charge process.
Continue charging (CONTI.): the alert is generated at the programmed percentage, but charging continues thereafter.
Stop (STOP): charging stops.
14. NiXX charge program
Page 3
Page 1
Page 2
CUT.TEMPER. : 55°C
MAX.CAPACITY: 150%
PEAK DELAY : 3min
TRI CURRENT : 100mA
SAFETY TIMER: 120min
Cut-off temperature
Max. capacity in x%
end of charge
peak detection dis-
abled for x minutes
Trickle charge current
Safety timer
Charge
Cycle
Discharge
11] NiMH 6S 3300mAh
CYCLE : C->D 1x 10m
CHG. : 3.3 A 5mV/C
DCHG. : 3.3A 0.8V/C
The following screen displays appear if you select the battery type NiXX.
The screen shows a maximum of four lines; pages 2 and 3 appear when
you move the Select arrow further down.
Cycle mode CYCLE
Cycle mode provides a means of charging and discharging a battery in
(multiple) cycles, e.g. in order to restore the pack’s normal performance
more quickly after a protracted period of storage.
Move the Select arrow to the CYCLE line, then press ENTER. The cycle
again. The cursor now moves to the number of cycles, where you can select any number in the range 1 to 10 cycles. Pressing ENTER causes the cursor
to move to the interval time (1 - 30 minutes), where you can enter the interval between the charge and discharge phases.
Note: Cycle mode uses the automatic charge and discharge modes, i.e. at this point you cannot pre-select any charge or discharge currents.
With the Select arrow at the Cycle mode line (CYCLE), start the process by holding the ENTER button pressed in for two seconds.
Charge CHG
altered using INC or DEC. The charge current is limited to 1C by default, i.e. if you enter 2200 mAh under battery capacity in the charge memory, the
charge current is automatically set to 2.2 A. The charge current can be set to any value in the range 0.1 to 20 A, taking the maximum charge power into
account. Depending on the power supply, the unit may be unable to charge at the selected current, i.e. the maximum possible current may not be used
for charging. If this should occur, the screen displays the charge current actually in use.
Operating Manual ULTRA DUO PLUS 80
