Operating Manual ULTRA DUO PLUS 80
24
Maximum capacity MAX. CAPACITY
If you enter a value for maximum capacity, then the charge process is automatically halted when this capacity is reached. The default setting is 120%.
The effective life of the battery can be increased by reducing this value.
SAFETY TIMER
The safety timer halts the charge process after the set time. The adjustment range is OFF to 300 minutes, the factory default setting is 120 minutes.
ENTER
Hold the ENTER button
pressed in for 2 sec. to
start the charge process
[ Pb ] CHARGE
*** BATTERY ***
*** CHECK ***
C-CV-CC : 0:00:12
CAPACITY : 10mAh
VOLTAGE : 12.612V
CURRENT : 2.80A
C-CV-CC : 0:01:25
INPUT VOLT : 14.222V
PEAK VOLT : 12.612V
AVG. VOLT : 0.000V
Mode
ESC
C-CV-CC : 0:02:59
BAT. TEMP. : 22.1°C
PEAK TEMP. : 22.1°C
BATTERY RES: 30mΩ
Mode
ESC
ESC
END
CHARGE
Hold the ENTER
button pressed in
for 2 sec. to stop
the charge process

11] Pb 6S 60000mAh
CHG. :
7.
0
A
2.3V/C
DCHG. : 5.0A 1.8V/C


0 ] NiMH 6S 3300mAh
CYCLE : C->D 1x 10m
CHG. : 3.3A 5mV/C
DCHG. : 5.0A 0.8V/C

0 ] NiMH 6S 3300mAh
CYCLE : C->D 1x 10m
CHG. : 3.3A 5mV/C
DCHG. : 5.0A 0.8V/C

0 ] NiMH 6S 3300mAh
CYCLE : C->D 1x 10m
CHG. : 3.3A 5mV/C
DCHG. : 5.0A 0.8V/C

0 ] NiMH 6S 3300mAh
CYCLE : C->D 1x 10m
CHG. : 3.3A 5mV/C
DCHG. : 5.0A 0.8V/C

0 ] NiMH 6S 3300mAh
CYCLE : C->D 1x 10m
CHG. : 3.3A 5mV/C
DCHG. : 5.0A 0.8V/C

Before starting a process please ensure that all parameters
are set correctly to match your battery type, and that the
battery is connected correctly to the charge output. Use the
INC or DEC button to move the Select arrow to the approp-
riate line: Charge (CHG) or Discharge (DCHG). With a brief
press on the ENTER button you can run through all the pa-
rameters of the selected mode once more, and adjust them
if necessary. Start the process by holding the ENTER button
pressed in for two seconds.
If you wish to alter the charge current during the charge pro-
is highlighted, and can be adjusted using the INC or DEC
button.
Pressing the MODE or ESC button switches between the
various charge displays. If you wish to halt the charge pro-
cess, hold the ESC button pressed in for two seconds.
18. Charging / discharging Pb batteries
