8. Charger controls
Ladeanschluss
„Akku “
Display
G4 connectors
for power supply
11...28 V DC
or
car batterie
12V DC
USB-Interface
(back side)
EH- BALANCER
CONNECTOR for
Graupner LiPo battery
„CH 2“
+
_
Connectors
for car battery
Charging jack
„CH 2“
Temperature sensor
„CH 2“
EH- BALANCER
CONNECTOR for
Graupner LiPo battery
„CH 1“
Charging jack
„CH 1“
Temperature
sensor
„CH 1“
Operating
buttons
Fan
(back side)
9
Operating Manual ULTRA DUO PLUS 80
