14
REMOVING BAGGER KIT
1. Lift thumb latch and remove hose from blower
assembly and inlet assembly (see figure 15 on
page 13).
2. Remove belt cover.
3. Remove V-belt from double pulley (see figure 13 on
page 12).
4. Remove blower assembly (see figure 11 on
page 11).
5. Re-install belt cover.
6. Install discharge chute.
7. Remove counterweights (see figure 7 on page 10).
8. Remove catcher assembly (see figure 6 on
page 9).
REMOVAL
CAUTION: Deflected material may cause injury.
ALWAYS operate mower with bagger cover
closed and secured, blower assembly fastened
securely, or with chute deflector in operating
position.
CAUTION: Always install counterweights on
front axle before operating unit with bagger
attached. Always remove counterweights from
front axle when bagger is removed from the unit.
