GB - 10
4. Seat - See Seat Adjustments on
page 13 and Service Position on
page 18.
5. Position Steering Levers - Remove
eccentric spacers and rotate steering
levers to the operating position. Reinstall
spacers. Tighten hardware securely.
See Aligning the Steering Levers
(Figure 14) on page 23.
6. Battery - Remove battery from unit and
charge (See Battery on page 21).
7. Check Engine Crankcase - Check and
add oil if needed. See Engine Manual for
specifications.
8. Fill Engine Fuel Tank - Add clean fuel to
the fuel tank.
NOTE: See engine manual for fuel type.
9. Hardware - Check for loose hardware.
10. Check Safety Interlock System - Check
to see that the interlock system operates
correctly (See Safety Interlock System
on page 12).
11. Lubrication - Lubricate all fittings per
maintenance label under seat and check
hydrostat oil level (See Lubricate Unit on
page 22).
12. On 60-inch Decks: Remove the
discharge chute from the transport
position and place the discharge chute
in the operating position.
13. Level Deck - Check unit to ensure deck
level set at factory has been maintained
(See Leveling the Mower Deck on
page 28).
14. Check Function of all Controls - Ensure
unit runs and performs properly.
1. Steering
Levers
2. Seat
3. Mounting
Hardware
OF4110
Figure 3
1
3
2
1
WARNING: FAILURE OF
INTERLOCK together with
improper operation can result in
severe personal injury.
WARNING: FAILURE OF
CONTROLS could result in death
or serious injury.
