Gravely 991096 - Controls and Features Overview; Ignition and Fuel System Controls; Steering and Parking Controls; Mower Lift and PTO Controls

EN - 15
1. Fuel Tanks and Caps
2. Steering Levers
3. Hydraulic Oil Reservoir
4. Ignition Switch
5. Hour Meter
6.
Throttle Lever
7. Choke Control (991079, 080, 081)
8. Power Take Off (PTO) Switch
9. Battery
10. Fuel Shut Off Valve
11. Mower Lift Pedal
12. Mower Deck
13. Mower Lift Lock
14. Seat Adjustment Lever
15. Parking Brake
16. Bypass Valve Lever
17. Oil Pressure Light
18. Seat Release Lever
19. EFI Malfunction Indicator Light
(991095, 096, 097)
CONTROLS AND FEATURES
1
2
3
9
10
11
12
13
14
15
8
4
5
17
7
6
16
Figure 4
18
19
