GB - 38
Short Term
Do not spray the unit with water, especially
when the unit is warm from operation. Water
can seep into bearings and damage them.
NEVER spray unit with high pressure water
or store unit outdoors.
Inspect unit for visible signs of wear,
breakage or damage.
Keep all nuts, bolts and screws properly
tightened and know unit is in safe working
condition.
Store unit in a cool, dry protected area.
Long Term
Clean unit thoroughly and lubricate. See
MAINTENANCE on page 17. Touch up all
scratched painted surfaces.
Remove weight from rear wheels by putting
blocks under frame or axle.
Fuel System
Gasoline left in the fuel system for extended
periods without a stabilizer will deteriorate,
resulting in gum deposits in the system.
These deposits can damage the carburetor
and the fuel hoses, filter and tank. Prevent
deposits from forming in the fuel system
during storage by adding a quality fuel
stabilizer to the fuel. Follow the
recommended mix ratio found on the fuel
stabilizer container.
To treat the fuel system for storage:
Add fuel stabilizer (Gravely p/n 00592900)
according to manufacturers’ instructions.
Run engine for at least 10 minutes after
adding stabilizer to allow it to reach the
carburetor.
NEVER store the engine with fuel in the fuel
tank inside of a building with potential
sources of ignition.
STORAGE
ACCESSORIES
Part No. Description
79211000 Hour Meter Kit
00592900 Fuel Stabilizer 4 oz.
79260500 36-in. Mulch Kit (988146)
79260000 48-in. Mulch Kit (988147)
79260400 52-in. Mulch Kit (988148)
78805100 Two-Wheel Sulky
SERVICE PARTS
Part No. Qty Description
07200518 1 Belt, Blade Drive
(988146)
07200519 1 Belt, Blade Drive
(988147)
00181711 1 Belt, Blade Drive
(988148)
D38006 1 Belt – Hydrostatic
Drive
00181251 1 Fuel Tank Cap
00590600 1 Fuse, 20 Amp
(988147, 148)
00888400 1 Relay (988147, 148)
01554800 1 Battery (988147, 148)
00669300 1 Hydraulic Filter
GDU10231 2 Mower Blade (988146)
GDU10230 3 Mower Blade (988147)
GDU10231 3 Mower Blade (988148)
