MAINTENANCE SCHEDULE
SERVICE PARTS
See your Gravely dealer to purchase service
parts for your unit.
Service Performed
Each Use Every 25 hrs. Every 50 hrs. Every 100 hrs. Every 400 hrs. Every 500 hrs.
Check Safety
Interlock System
•
Check Hydraulic
System
•
Check Engine Oil * •
Change Engine Oil *
Check Tire Pressure •
Check Mower
Blades
•
Check Air Filter * •
Check Carbon
Canister Filter
•
Lubricate Unit •
Check Parking
Brake
•
Clean Battery •
Clean Engine
Cooling System *
•
Check Fasteners •
Check Belts •
Change Hydraulic
Oil and Filter **
•
Lubricate Caster
Fork Bearings
•
Lubricate Caster
Wheel Bearings
•
Adjust Clutch‡ •
* Refer to engine manual for instructions.
** Change after first 75 hours of operation.
‡ Adjust clutch every 500 hours or once per
season if used less than 500 hours.
Common Service Parts
Description Qty. Part No.
PTO Belt (Engine to Deck)
– 52"
1 07200729
Mower Drive Belt – 52" 1 07200036
Mower Blade – 52" 3 00450300
Mulching Blade – 52" 3 04887600
PTO Belt (Engine to Deck)
– 60"
1 07234600
Mower Drive Belt – 60" 1 07200038
Mower Blade – 60" 3 09081200
Mulching Blade – 60" 3 04887700
PTO Belt (Engine to Deck)
– 72"
1 07200731
Mower Drive Belt – 72" 1 07200039
Mower Blade – 72" 3 04774600
Mulching Blade – 72" 3 04887800
Transaxle Drive Belt 1 07200515
Fuel Stabilizer – 118 ml
(4 oz)
• (Except Canada)
• For Canada Only
A/R
04730300
04742400
Hydraulic Oil Filter 2 21548300
Hydraulic Oil and Filter Kit 1 59222800
Relay A/R 04438400
Model 992267
Description Qty. Part No.
Air Filter 1 21500010
Engine Oil Filter 1 21397200
Spark Plug 1 21500009
Fuel Filter 1 21545700
24 x 12-12 Tire 1 07101043
Models 992268, 992269, 992270
Description Qty. Part No.
Air Filter (Outer) 1 21545400
Air Filter (Inner) 1 21545300
Engine Oil Filter 1 21535800
Spark Plug 2 21536100
Fuel Filter 1 21538400
23 x 10.5-12 Tire (Model
992268)
1 07101043
24 x 12-12 Tire (Models
992269, 992270)
1 07101041
Models 992271, 992272
Description Qty. Part No.
Air Filter (Outer) 1 21537000
Air Filter (Inner) 1 21536900
Engine Oil Filter 1 21397200
Spark Plug 4 21550333
Fuel Filter 1 21550332
23 x 10.5-12 Tire (Model
992271)
1 07101043
