Gravely Treker 996122 - Exhaust Components

47
EXHAUST COMPONENTS
Model 996122, 996124, 996143, 996144
Item Part No. Description
1 04071600 ENGINE MANIFOLD, SUBARU
2 04071601 MUFFLER, SUBARA
3 840-315C SPARK ARRESTER WITH SCREW
4 801-183C SCREW HEX SLT 8-18X1/2 PLT
5 700-517D SHIM, MUFFLER MOUNTING
6 807-219C SPRING EXT. .5ODX1.68LGX.08W
7 801-193C SCREW, HEX #8 X 1/2 SELF TAP
8 802-735C HHCS 5/16-18 X 3/4 GR5 YELLOW DI
9 804-084C WASHER, FLAT 5/16-18 FLG
10 803-177C NUT HEX LOCK 5/16-18 FLG
11 04083000 GASKET, SUBARU
12 803-220C NUT HEX FLANGE M8X1.25 PLT
12
11
1
7
11
6
2
8
9
5
10
3
4
