Gravely Treker 996122 - Shock Rear

8
SHOCK REAR
Model 996122, 996124, 996143, 996144
Item Part No. Description
1 840-101C SHOCK COIL REAR TRUCK
2 802-751C HHCS M14X2.00X60 GR8.8
3 803-334C NUT HEX NYLOCK M14X2.00
4 803-319C NUT HEX TOP LOCK 9/16-12 YLW
5 700-262H TRAILING ARM RH WELDMENT
6 817-517C BUSHING IDLER ARM RUBBER
7 700-371H CENTER PIVOT TUBE WELDMENT
8 700-422H TRAILING ARM PIVOT BOLT WELDMENT
9 815-145C RH DRUM ASM 18 OMM 4 ON 4" BC
10 802-731C HHCS M8 X 1.25 X 30 GR 10.9 YLW PLT
11 804-157C WASHER SPRING LOCK M8 PLT
1
3
2
4
5
6
8
9
11
7
10
2
