GREAT VIGOR Cage - Throttle and Brake Linkages

Step 37
Throttle and Brake Linkages
37A - Grub Screw w/Threadlock 3x3mm -- 6
37C - Button Head Tapping Screw 3x12mm -- 1
37B - Spring 8.3mm -- 2
37D - Spring 18mm -- 1
SE002
37A
<37-1>
SE002
MV12605
SE0031Y
SE0031Y
37D
60mm
15mm
24mm
<37-2>
MV12605
SE002
37B
80mm
MV12605
SE002
SE002
MV12605
37B
36A
37A
37A
Servo Arm
(Included with Servo)
37C
Step 37-1
Step37-2
