GREAT VIGOR Cage - Front Gearbox; Front Shock Tower and Chassis Brace

2B
2A - Button Head Tapping Screw 3x38mm -- 2
2D - Grub Screw w/Threadlock 5x4mm -- 1
Front Gearbox
Step 2
<2-1>
MV22821
(13T)
2F - Shim 8x12x0.4mm -- 1
2G - Ball Bearing 8x16x5mm -- 2
3B - Button Head Tapping Screw 3x12mm -- 1
2B - Button Head Tapping Screw 4x12mm -- 2
2G
2F
MV162D4
MV1173
2G
XV1631
Step 2-1
Step 1
XV1631
XV1657
2C
XV162U1AL
2A
2D
Front Shock Tower and Chassis Brace
Step 3
2C - Button Head Tapping Screw 3x10mm -- 1
3C - Lock Nut 3mm -- 4
3A - Lock Nut 4mm -- 1
XV1625F1
3C
3C
3A
MV110
MV110
3B
3D
3F
Step 2
3E
XV1321AL
3F - Cap Screw 4x50mm -- 1
3D - Cap Screw 3x18mm -- 4
3E - Cap Screw 3x25mm -- 2
2E - Grub Screw 4x4mm -- 1
MV3618F
(XV3611)
2E
