GREAT VIGOR Cage - Step 1 Front, Rear and Centre Differentials

Step 1
Front, Rear and Centre Differentials
1A - O-Ring 3x1mm -- 12
1B - Pin 2.5x12.8mm -- 6
1C - Pin 4x26.6mm -- 6
1C
MV22873
MV22873
1C
MV22873
<1-1>
MV22873
MV22873
Step 1-1
1B
1E
1G
MV22873
MV11721
MV11711
For Centre (x1)
For Front and Rear (x2)
For Front and Rear (x2)
For Centre (x1)
Differential Oil -- 1
1E - Grub Screw 4x3mm -- 3
1F - F/H Tapping Screw 3x16mm -- 12
1G - Ball Bearing 8x16x5mm -- 6
1D - Shim 8x12x0.4mm -- 3
1B
Differential
Oil
MV22873
1F
1D
1A
MV11721
1G
1F
MV22811
(43T)
MV11711
1A
1G
1D
1F
1F
MV22832
(48T)
MV22873
Differential
Oil
1B
1A
