Gree FGR30Pd/DNa-X

GREE Duct type split Air conditioner Inverter Series
3
3 Specifications
Model Heat Pump FGR20Pd/DNa-X FGR25Pd/DNa-X
Capacity
Cooling T1/T3
Btu/h
68300/47000 85300/59700
Heating
Btu/h
75100 93800
EER T1/T3 Btu/(W.h) 8.8/6.7 9.1/6.8
COP Btu/(W.h) 10.7 10.5
Power Supply
Ph/V/Hz
3N/380-415/(50/60)
3N/380-415/(50/60)
Power input
Cooling T1/T3 kW 7.8/7.0 9.4/8.8
Heating kW 7.0 8.9
Rated Current(OD) A 18.5 24.6
Rated Input(OD) W 10000 11000
Refrigerant Charge Volume kg 6.4 8.0
Indoor unit
Airflow Volume
CFM 2178 2472
m
3
/h 3700 4200
ESP
Rated Pa 120 120
Range Pa 0-250 0-250
Sound Pressure Level
dB(A)
52
53
Dimension
(W×D×H)
Outline mm 1315×760×385 1520×840×450
Package mm 1578×883×400 1788×988×465
Net Weight/Gross Weight kg 82/104 99/134
Outdoor unit
Sound pressure level dB(A) 62 63
Dimension
(W×D×H)
Outline mm 940×320×1430 940×460×1615
Package mm 1033×433×1580 1033×573×1765
Net Weight/Gross Weight kg 120/130 146/162
Connection
pipe
Outer
diameter
Liquid Inch(mm) Φ3/8 Φ3/8
Gas Inch(mm) Φ3/4 Φ7/8
Max. distance
Height
mm
30
30
Length mm 70 70
Loading
quantity
20'GP/40'GP/40'HQ set 12/24/24 10/20/22
Model Heat Pump FGR30Pd/DNa-X FGR40Pd/D(2)Na-X
Capacity
Cooling T1/T3 Btu/h 102400/71700 136500/95500
Heating Btu/h 112600 146700
EER T1/T3 Btu/(W.h) 9.1/6.8 8.9/6.8
COP Btu/(W.h) 10.9 10.1
Power supply Ph/V/Hz 3N/380-415/(50/60) 3N/380-415/(50/60)
Power input
Cooling T1/T3 kW 11.3/10.5 15.4/14.0
Heating kW 10.3 13.9
Rated Current(OD) A 26.6 39.4
Rated Lnput(OD) W 13500 20000
Refrigerant Charge Volume kg 9.5 6.4×2
Indoor unit
Airflow Volume
CFM 3060 4120
m
3
/h
5200
7000
ESP
Rated Pa 120 120
Range Pa 0-250 0-250
Sound Pressure Level dB(A) 55 56
Dimension
(W×D×H)
Outline mm 1520×840×450 1680X900X650
Package mm 1788×988×465 1923X1153X850
Net Weight/Gross Weight kg 105/145 165/210
