Gree FP-102BA2/B-D User Manual

Wall Mounted Type
Fan Coil Unit Service Manual
8
PRODUCT
Model FP-85BA2/A-D
Product Code EM55001590
Air ow volume
High
m
3
/h 1000
CFM 588
Medium
m
3
/h 840
CFM 493
Low
m
3
/h 720
CFM 423
Capacity
Cooling W 5400
Heating W 8500
Power system
Type V-Ph-Hz 208-230V~ 60Hz
Input W 70
Water system
Water ow volume
m
3
/h 0.88
GPM 3.87
Pressure drop
kPa 63
Ft·WG 20.7
Coil
Type Aluminum n-copper tube
Operating pressure MPa ≤1.6MPa
Motor
Type FN20W-PG
Capacitor uF 1.5
Power output W 20
Sound pressure level dB(A) 49
Connection pipe size
Water inlet &outlet inch 1/2"
Condensing water drain mm 15.6
Outline dimension (W×D×H) mm 940×200×298
Package dimension (W×D×H) mm 1010×285×380
Net weight kg 13
Gross weight kg 17
Loading quantity
20'GP 290
40'GP 595
40'HQ 671
Standard wireless remote controller YB1FA
