Gree FP-102BA2/B-D User Manual

9
Wall Mounted Type
Fan Coil Unit Service Manual
PRODUCT
Model
FP-34BA2/B-D
FP-34BA3/B-D
FP-34BA5/B-D
FP-51BA2/B-D
FP-51BA3/B-D
FP-51BA5/B-D
FP-68BA2/B-D
FP-68BA3/B-D
FP-68BA5/B-D
FP-85BA2/B-D
FP-85BA3/B-D
FP-85BA5/B-D
FP-102BA2/B-D
FP-102BA3/B-D
FP-102BA5/B-D
Code
EM55000320
EM55001760
EM55001890
EM55000330
EM55001800
EM55001900
EM55000340
EM55001770
EM55001910
EM55000350
EM55001780
EM55001920
EM55000360
EM55001790
EM55001930
Air ow volume
High
m
3
/h
360 550 680 850 1000
CFM 212 324 400 500 588
Medium
m
3
/h 322 413 591 708 840
CFM 189 242 347 416 493
Low
m
3
/h
282 367 532 616 720
CFM
166 215 312 362 423
Capacity
Cooling W 2100 2700 3600 4200 5400
Heating W 3150 4050 5400 6300 8500
Power
system
Type V-Ph-Hz 208-230V~ 60Hz
Input W 50 60 70
Water
system
Water ow
volume
m
3
/h
0.4 0.45 0.64 0.78 0.88
GPM 1.76 1.98 2.82 3.43 3.87
Pressure drop
kPa 13 24 44 45 63
Ft·WG 4.3 7.9 14.5 14.8 20.7
Coil
Type Aluminum n-copper tube
Operating
pressure
MPa ≤1.6MPa
Motor
Type FN20X-PG FN20W-PG
Capacitor uF 1 1.5
Power output W 20
Sound pressure level dB(A) 35 40 43 48 49
Connection
pipe size
Water inlet
&outlet
inch 1/2"
Condensing
water drain
mm 15.6
Outline dimension
(W×D×H)
mm 845×180×275 940×200×298
Package dimension
(W×D×H)
mm 915×255×355 1010×285×380
Net weight kg 11 13
Gross weight kg 14 17
Loading quantity
20'GP
365 290
40'GP
765 595
40'HQ 850 671
Standard wireless remote controller YB1FA(X-FAN)

Gree FP-102BA2/B-D Specifications

General

Brand	Gree
Model	FP-102BA2/B-D
Category	Air Conditioner
Language	English
